RV Accumulator Tank w/Barbed Fitting Water Pressure Vacuum Tank Internal Bladder 125 psi 0.75L 92773405
Description:
The accumulator tank holds a reservoir of air and water down stream from the pump. The air acts as a cushion, absorbing pressure variations creating a smoother flow and reducing the cycling of the pump,especially at lower flows.
Low power consumption, no noise during use, avoiding frequent opening of the safety valve and frequent refilling of the automatic water replenishment valve.
Features:
Internal Bladder
Smoother flow
Reduces on/off switch cycling
Quieter water system
Long pump life
Easily fitted to new or existing systems
Compact size
1/2" MNPT port fittings
Mounting point for optional pressure switch
Specifications:
Condition: 100% Brand New
Type: Water Accumulator Tank
OE Number: 182-200, 182200
Internal volume: 0.75L
Pre-charged pressure: 10 PSI
Max operating pressure: 125 PSI
Inlet/outlet diameter: 1/2" MNPT
Comes with (2) 1/2" barbed fittings
Approvals: CE
Package Includes:
1x Accumulator
2x Connector
Applications:
-Yacht/RV/caravan pressurized water system
-Sprayer fixtures (vehicle-mounted and electric sprayer)
-Clean machine, humidifier, water purification and medical apparatus
-Food beverage filling and liquid transfer
-Any other pressurization system
Note:
1. Relieve air pressure prior to disassembly
2. Do not use to pump flammable fluids, gasoline, kerosene fuel oil, ect.
3. Do not use pump in a explosive environment or use where flammable vapors are present
4. Do not use to pump gasoline, Petrol or fluids with flash point below 37°C(98°F), explosion or death may occur.
5. The accumulator tank comes pre-pressurized at 10 PSI. Before Using Adjust air pressure in tank 3 PSI(0.2 bar) below water pump switch cut in pressure.
6. Do not over pressurize tank. Pressures over 125PSI(8.6BAR) may rupture tank and cause personal injury.
