Intake Manifold Fit For LS1 5.3L LS2 6.0L300-130 MT023024 22821286
GT-22821286
5 In stock
$339.04
Specifications: Material: Aluminum Finish: Black Reference Number: 300-130 Carbureted or Throttle Body EFI Dual Plane RPM Range: 1,500-6,500 4150 Square Bore Carb Base (Accepts Up To 1.75" Dia. Throttle Bores) 3/8" NPT Vacuum Port 1/8" NPT MAP Sensor Port Rectangular Ports Designed To Fit Cathedral Port Heads Port Dimensions:...
customers are viewing this product
Specifications:
Material: Aluminum
Finish: Black
Reference Number: 300-130
Carbureted or Throttle Body EFI Dual Plane
RPM Range: 1,500-6,500
4150 Square Bore Carb Base (Accepts Up To 1.75" Dia. Throttle Bores)
3/8" NPT Vacuum Port
1/8" NPT MAP Sensor Port
Rectangular Ports Designed To Fit Cathedral Port Heads
Port Dimensions: 2.72" x 1.00"
Intake Height: 6.15" Front, 5.07" Rear (Valley Cover to Carb Base Flange)
Direct Replacement, Easy Installation
Strict QC & Fitment Tested
Package including:
1 X Intake Manifold
9 X O-Rings
Mounting Hardware
As Shown in the Picture above.
Fitment:
For LS1 5.3L LS2 6.0L
